Frame
META POWER SX 800, 180 mm travel
29''-27.5'', Alloy 6066, triple butted tubes, T4, T6. Bolu bearings
-
Motor
BOSCH Performance Line CX Gen5
100 n.m
-
Battery
BOSCH Powertube 800
Fully integrated main battery, 800 Wh
BOSCH 4A Battery Charger. Compact size & lightweight
-
Display
BOSCH System Controller, ON/OFF switch, assist mode level, battery charge level
Switch: BOSCH Mini Remote, mode switch, walk assist, light switch
-
Shock
ROCKSHOX Super Deluxe Select
230 x 65 mm, Debonair +, 2-postion (open/firm) lever, Rebound
-
Fork
ROCKSHOX ZEB Ultimate, 180 mm
29", Charger 3.1 damper, HSR, LSR, HSC, LSC, Boost (15 x 110 mm), 44 mm offset
-
Headset
ACROS ZS56 / ZS66
Alloy cups, stainless steel & sealed bearings
-
Stem
RIDE ALPHA 40
40 mm extension, 31.8 mm
-
Handlebar
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL
31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
-
Grips
RIDE ALPHA Mushroom
Soft compound, single clamp, black
-
Brakes
TRP DH-R EVO PRO, 4 pistons, resin pads
Rear rotor: TRP RS05 203 mm - Front rotor: TRP RS05 220 mm
6-bolt, 2.3 mm width
-
Shifters
SRAM Eagle 90
12s
-
Chain guide
RIDE ALPHA
32-34t
-
REAR DERAILLEUR
SRAM Eagle 90
12s
-
Crankset
E13 Helix Core E*Spec, 155 mm crank arms, Bosch
Chainring: SRAM E-MTB T-Type, 34t for Bosch system, direct mount
-
Chain
SRAM GX T-Type
12s, Flattop
-
Cassette
SRAM XS 1270 T-TYPE
12s, 10-52t
-
Rims
DT SWISS H1900
Rear: 27.5'', 28h, 30 mm inner width - Front: 29'', 28h, 30 mm inner width
-
Hubs
DT SWISS 370
Rear: 28h, sealed bearings, 12 x 148 mm, SRAM XD - Front: 28h, sealed bearings, 15 x 110 mm
-
Spokes/nipples
Included with wheelset
-
Tyres
Rear: MAXXIS Minion DHRII 27.5'' - Front: MAXXIS ASSEGAI 29''
Rear: 27.5x2.50 WT, 3C MaxxTerra, Double Down, TR - Front: 29x2.50 WT, 3C MaxxGrip, New EXO+, TR
-
Seat post
KS Ragei
34.9 mm, 125 mm on S, 170 mm on M and 190 mm on L/XL
-
Saddle
FIZIK Terra Aidon X5
145 mm width, Kium Mobius rails
-
Weight
25,5 KG / 56.22 LB
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
-
Pedals included
CRANKBROTHERS Stamp 1
-
Colour
Pure White
Shiny Finish
-
Accessories
Down tube protector, chainstay protector, seatstay protector, ZEB fork fender, FIDLOCK base, BOSCH Kiox 400
